LC650EGE-FKM1 LG Display 65" 3840(3)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY

Name: LC650EGEFKM1 LG Display 65quot 384032160 500 cdm INDUSTRIAL LCD DISPLAY
Brand: LG Display
Price: 60 USD

Best LC650EGE-FKM1 LG Display 65" 3840(3)×2160 500 cd/m² INDUSTRIAL LCD DISPLAY wholesale

Brand Name : LG Display

Model Number : LC650EGE-FKM1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 100PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

Price : 60USD

MODEL NUMBER : LC650EGE-FKM1

BRAND : LG Display

SIZE : 66 inch

BRIGHTNESS : 500CD/M2

Lamp Type : WLED

RESOLUTION : 3840(3)×2160, UHD, 68PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LC650EGE-FKM1 Application Details

Basic Info :	Panel Brand LC650EGE-FKM1Panel Model Diagonal Size 65" Application a-Si TFT-LCD , LCMPanel Type Model Alias LC650EGE (FK)(M1)
Reliability :	Operating Temp. 0 ~ 50 °C Storage Temp. -20 ~ 60 °C

LG Display LC650EGE-FKM1 Mechanical Details

Pixel Features :	Pixel Format 3840(3)×2160, UHD Dot Pitch 0.124×0.372 mm (H×V) Configuration RGBW Vertical Stripe Pixel Pitch 0.372×0.372 mm (H×V) [68PPI]
Mechanical Size :	Display Area 1428.48×803.52 mm (H×V) Bezel Area 1433.4×808.1 mm (H×V) Outline Dim. 1450.6×833.366 mm (H×V) Outline Depth 15.17 (Typ.) mm
Outline Features :	Form Factor Flat Rectangle Orientation Landscape type Aspect Ratio 16:9 (H:V) Shape Style
Other Features :	Weight 18.2/19.1Kgs (Typ./Max.) Surface Antiglare (Haze 3%), Hard coating (3H)

LG Display LC650EGE-FKM1 Optical Details

Basic Information :	Brightness 500 cd/m² (Typ.) Contrast Ratio 1200:1 (Typ.) (Transmissive) Viewing Angle 89/89/89/89 (Min.)(CR≥10) Optical Mode IPS, Normally Black, Transmissive Viewing Direction Symmetry Response Time 8 (Typ.)(G to G) ms
Color Performance :	Chromaticity Wx:0.281; Wy:0.288 Color Numbers 1.07B (8-bit + Dithering) Color Temperature 9966K Uniformity 1.54 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio 81% sRGB 100% coverage Adobe RGB 78% coverage DCI-P3 83% coverage Rec.2020 61% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LC650EGE-FKM1 Backlight Details

Back-light Features :	Lamp Type WLED Amount - Life Time 30K(Min.) (Hours) Replacement - Lamp Shape - Position Edge light type
Lamp Electrical :	Voltage Input 135.8/140.6/150.7V (Min./Typ./Max.) Current Input 120±6mA Consumption 101.2/113.9W (Typ./Max.)
Interface Features :	Type Connector Position - Lamp Driver No
Interface Detail :	Brand Model Pin Pitch Pins Amount Configuration UJU HS100-L08N-N62 1.0 mm 8 pins 1 pcs BLE-8PINS-CCCNNNNA UJU HS100-L08N-N62-A 1.0 mm 8 pins 1 pcs BLE-8PINS-ANNNNCCC

LG Display LC650EGE-FKM1 Interface Detail

Signal Systerm :	V-by-One 8 lane Logic Voltage -
Signal Electrical :	Voltage Input 12.0V (Typ.) Current Input 1.21/1.57A (Typ./Max.) Consumption 14.5/18.9W (Typ./Max.)
Interface Features :	Type Connector Position
Connector Detail :	Brand Model Pin Pitch Pins Amount Configuration JAE FI-RXE51S-HF 0.5 mm 51 pins 1 pcs

LG Display LC650EGE-FKM1 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	16 pcs / box	-	1600×1140×1053 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
